Multiphase flows are an integral part of a large number of industrial processes of current interest. As new strategies are introduced to produce environmentally benign fuels, increase recycling, use current resources more efficiently, manage higher heat loads, increase production of food and feed, manufacture complex objects, and pull CO2 from the atmosphere, understanding, predicting, and controlling their behavior will therefore be of ever greater importance. Over the last few decades, direct numerical simulations, where every continuum spatial and temporal scales are reproduced for large and complex systems, have greatly increased our insight and understanding. Current success opens up the opportunities to examine even more complex problems and many current and future industrial processes involve tightly coupled physical processes taking place on widely different scales. Even when each process is well understood, their collective behavior remains poorly understood and can only be predicted by simulations of the whole system.

Numerical Simulations

Direct numerical simulations of multiphase flows go back to the very beginning of computational fluid mechanics and as the field has advanced, many possible strategies to simulate those systems accurately and efficiently have been explored. In some cases the majority of practitioners have conclusively converged on certain strategies, such as the use of the one-field, or one fluid, formulations of the governing equations, but for other aspects various groups remain committed to historical approaches, even when better methods are available. As the need to consider more complex systems becomes more urgent, making the most versatile and accurate approaches available to the largest number of researchers must become a priority.

Numerical Methods

The key to our ability to simulate a wide variety of multiphase flows is the front tracking method introduced in a 1992 Journal of Computational paper. As in many other methods, the conservation equations are solved on a fixed, usually structured, grid and the different phases or fluids identified by a marker or index function that moves with the fluid velocity. Advecting the marker function on the fixed grid is surprisingly challenging and several ways have been proposed to do so. We bypass those challenges by tracking the phase boundary using a separate, usually unstructured, grid and construct the marker function from the interface grid. This results in an accurate and versatile method that has been successfully used to simulate a very large number of multiphase systems, in many cases for the first time. Here is a simple introduction to the method, using Matlab codes for 2D flows. For more details, including references to extensions to flows with heat transfer, phase changes (boiling and solidification), surfactants,chemical reactions, electric fields, and other physical processes, click here.

Here is a Bibtex File with journal papers, book chapters, Ph.D. Dissertations and conference papers. The list of conference papers is very incomplete.
